Specifications

General

Series Name Logic
Type Built-In
Color Stainless Steel
Manufacturer Color TouchProof™ Stainless Steel
Place Settings 16
Tub Material Stainless Steel
Silence Rating 40 dB

Cycle Information

Number of Cycles 9
Wash Cycles
• Rinse and hold program
• Intensive program
• Sanitize
• Auto wash
• Standard
• Time program
• Anti odour
• Quick Pro wash
• Self-cleaning
Options
• Sensor-controlled door opening - optimizes the drying process according to the room temperature
• Time set
• Heat Boost Mode
• Green mode - less energy and water is used; the program time is extended
• Enable/disable automatic door opening
• Speed mode - the program time is shortened; more energy is used
• Night mode - lower noise level; the program time is extended
• Super Rinse™ - 2 extra rinses

Features

Technologies
• 8 Steel™
• Super Cleaning System™
• Cutlery Spray™
• Aqua Level™ Sensor: Ensures an optimized water level
• Sensi Clean™ Sensor
• Status Light™
• Aqua Detect™: Instant recognition of any leakage in the motor compartment
• Anti Block™: Self-cleaning drain pump
• Kid Safe™: Lockable controls
Aqua Safe™:
• Sealing points outside the container
• Waterproof bottom plate
• Detection of water leakage on the bottom plate
• Stand-by water protection: Leakage detection when the machine is off
• Extra durable PEX inlet hose
• Maximum time for water intake
• Light and sound alarm
Delay Start Information Possible to delay up to 24 hours
Delay Start Yes
3rd Rack System Yes
Control Lock Yes
Cutlery Tray Yes
Silverware Basket Yes
Wi-Fi Yes

Additional Information

Installation: Built under a countertop

Number of spray arms: 3 pcs

Number of spray zones: 9Stainless steel spray arms

Exterior handle: T-Bar

Interior light: 2 LED lightsLCD display

Remaining time indication

Wash end indication: Displayed with sound and lightMain wash temperature (°F): 131/140/149/158

Rear leg is adjustable from the frontPossible to install elevatedIndication of low level of rinse-aid: Notification in display

Duration of standard program: 125 min

Max. temperature of inflow water: 140 °F

Estimated annual water consumption: 647.5 gal

Water consumption: 3 gal

Required inlet water pressure psi: 0,03-1Top tray:Easy height adjustment

With telescopic railsHandle

Guide rails with ball bearings

Upper basket type:Exclusive - Nylon coated steel baskets, all tines rows are foldable, divisible/foldable wine shelves

Light Lock™ for fastening lightweight items

Rack height adjustable

Upper basket:Perfect ergonomy with easy sliding telescopic rails

Small distance between the basket threads - makes loading easy and prevents small items to fall throughLight Lock™ for fastening lightweight items

China Guard - Protects fragile load from the rotating spray armExtra wide knife stand

Dividable pin rowsWine glass fixings in TPE2 foldable glass supports

Handle with ASKO logo

Sliding tines for easy adaptation to stoneware etc.

Foldable wine shelves to the right

Divisible/foldable wine shelves to the leftLower rack:ExclusiveFoldable/divisible rear tine rowVase/bottle holder for cleaning vases/baby bottlesFoldable/divisible front tine row

Cutlery basket

Small distance between the basket threads - makes loading easy and prevents small items to fall throughHandle with ASKO logoSliding tines for easy adaptation to stoneware etc.

Electrical Information

Information
• Estimated yearly energy consumption: 220 kWh
• Energy consumption - normal program: 1 kWh
• Power consumption in standby mode: 0.5 W
• Connected load: 1300 W
• Voltage: 120 V
• Fuse: 15 A
• Frequency: 60 Hz

Accessories

Included Installation: Multi-fit outlet hose, integrated anti-siphon, trim kit, steam protection strip

Dimensions

Class Width 24"
Width 23.94 inch(es) / 60.81 cm
Height (Min.) 34.29 inch(es) / 87.1 cm
Weight 95.9 lb(s) / 43.5 kg
Additional Dimensions
• Depth: 21.81 "
• Depth with door open: 48.46 "
• Maximum product height: 36.38 "
• Length of electrical cord: 71.46 "
• Length inlet hose: 64.17 "
• Length outlet hose: 90.55 "
• Min. niche width: 23.94 "
• Min. niche height: 34.25 "
• Depth (incl. wall spacing): 21.85 "
• Height setting: 2.08 "
• Adjustable kick plate: 30-94/0

Shipping Dimensions

Width 25.19 inch(es) / 63.98 cm
Height 36.61 inch(es) / 92.99 cm
Depth 26.77 inch(es) / 68 cm
Weight 103.18 lb(s) / 46.8 kg
